Solar Triangle Brackets
Four-hole triangle connectors for bracing and joining PV support members in project-specific frames.
These are RFQ-ready reference SKUs. Final revision, compliance documents and commercial terms are confirmed per order.
Technical specification
| size | 140 × 60 to 150 × 80 mm |
|---|---|
| thickness | 2.0–3.0 mm |
| holes | 4-hole |
| use | PV frame bracing |
Product facts
The following points are stated so this page can be cited accurately.
- Specifications shown here are taken from the current JINXI product catalogue (JX-SOL-TRI-140) and are confirmed at order.
- The minimum order quantity (By configuration) and lead time (12–20 working days) are typical catalogue values; final MOQ and delivery are confirmed per quotation.
- No reference drawing is published for this SKU; geometry and tolerances are confirmed per order.
- Compliance documents such as material certificates, test reports and declarations of conformity are prepared and confirmed per order.
- This page does not state a price, stock level, country of origin, certification status or EU responsible person; those are confirmed with the quotation.
Frequently asked questions
What are the typical MOQ and lead time for Solar Triangle Brackets?
The JINXI catalogue lists By configuration and 12–20 working days for JX-SOL-TRI-140. These are typical values; the final MOQ and delivery date are confirmed when we quote your order.
Are the drawings for Solar Triangle Brackets manufacturing-ready?
No reference drawing is published for this SKU; geometry and tolerances are confirmed per order.
Which standards and compliance documents apply to Solar Triangle Brackets?
Compliance documents such as material certificates, test reports and declarations of conformity are prepared and confirmed per order. Tell us which documents your project or market requires when you request a quote.
How do I request a quote and what are the commercial terms?
Use the “Request a quote” button on this page with your required quantity and destination. Default Incoterms are FCA Foshan or DAP named place. Payment is T/T, 30% deposit / 70% before shipment on a first order, with L/C possible after a track record.
What material and finish does Solar Triangle Brackets use, and where are the full dimensions?
Zn-Al-Mg coated steel / hot-dip galvanised steel, with a Zn-Al-Mg coated / hot-dip galvanised finish. Full dimensions are listed in the technical specification table above; the complete specification is confirmed at order.
